特性Feature
|
單位
|
|
|
型號Model
|
|
P13
|
P15
|
P20
|
P20
|
P20
|
P20
|
|
配置號 Configguiation NO.
|
|
600
|
610
|
100
|
150
|
460
|
470
|
|
額定載重 Load capacity
|
kg
|
1300
|
1500
|
2000
|
2000
|
2000
|
|
載荷中心距(C) Load center
|
mm
|
600
|
|
軸距 Wheel base
|
mm
|
1165
|
1234
|
1505
|
1390
|
1493
|
1480
|
|
操作類型 Operating type
|
|
步行式/Walkie
|
步行式/乘駕式Walkie/Stand Oh
|
|
車輪Wheels
|
|
|
|
|
|
|
|
|
輪子類型（前/后）Wheels type
|
|
PU
|
|
輪子數量-驅動輪/平衡輪/承重輪數量Wheel quantity Driving wheel/Balance wheel/Bearing wheel
|
|
1/4/2
|
1/4/1
|
1/4/2
|
|
驅動輪尺寸Driving wheel size
|
mm
|
?252×67
|
?266×126
|
?248×75
|
|
承重輪尺寸Balance wheel size
|
mm
|
?80×58(雙輪/Double wheels)
|
?80×80(雙輪/Double wheels)
|
|
平衡輪尺寸Bearing wheel size
|
mm
|
?99.5×40
|
?90×48
|
?115×55
|
|
尺寸Demension
|
|
|
|
|
|
|
|
|
貨叉zui低離地高度Min.fork lowered height
|
mm
|
85
|
|
貨叉zui大起升高度Max.fork lifting height
|
mm
|
205
|
195
|
205
|
|
zui大起升行程Max.lifting height
|
mm
|
120
|
110
|
120
|
|
貨叉外側間距Overall fork width
|
mm
|
540/600/685
|
|
貨叉長度Fork length
|
mm
|
1150/1200
|
|
貨叉寬度Fork width
|
mm
|
160
|
185
|
|
貨叉厚度Fork thickness
|
mm
|
44
|
55
|
|
整車全長，踏板收起/f放下Overall length
|
mm
|
1520
|
1630
|
1852
|
1750
|
1916/2333
|
1920/2335
|
|
車體寬度Overall width
|
mm
|
704
|
724
|
764
|
720
|
790
|
720
|
|
整車高度（含手柄）Overall height(With handle)
|
mm
|
1255
|
1220
|
1380
|
1385
|
1455
|
|
整車高度（不含手柄）Overall height(Without handle)
|
mm
|
680
|
685
|
765
|
850
|
845
|
900
|
|
zui小轉彎半徑，踏板收起/放下Min.Turning radius
|
mm
|
1400
|
1400
|
1667
|
1575
|
1746/2158
|
1735/2140
|
|
zui小直角堆垛通道寬度，踏板收起/放下（托盤800*1200,1200沿貨叉放置)Min.Aisle width for pallets 800*1200
|
mm
|
1760
|
1817
|
1920
|
1900
|
2046/2435
|
2060/2451
|
|
zui小直角堆垛通道寬度，踏板收起/放下（托盤1000*1200,1200沿貨叉放置)Min.Aisle width for pallets 1000*1200
|
mm
|
1805
|
1858
|
1950
|
1940
|
2077/2458
|
2090/2468
|
|
性能Performance
|
|
|
|
|
|
|
|
|
zui大行駛速度，載貨/空載Travel speed,laden/unladen
|
km/h
|
3.5/4
|
5/5
|
4/4
|
6/6
|
|
zui大起升速度，載貨/空載Lift speed,laden/unladen
|
mm/s
|
56/60
|
|
zui大下降速度，載貨/空載Lowering speed,laden/unladen
|
mm/s
|
57/59
|
|
爬坡度，載貨/空載Gradeability,laden/unladen
|
%
|
5/7
|
|
電氣配置Electrical configuration
|
|
|
|
|
|
|
|
|
驅動電機Drive motor
|
KW
|
DC0.63
|
DC0.93
|
AC1.5
|
|
起升電機Lift motor
|
KW
|
DC0.8
|
DC2.0
|
|
轉向電機Steering motor
|
KW
|
/
|
DC0.15
|
|
蓄電池電壓/r容量bBattery voltage/capacity
|
V/Ah
|
24/70
|
24/210
|
24/270
|
24/280
|
|
制動Brake
|
|
電磁/再生Electromagnetic/Regenerative
|
|
控制器型號Controller
|
|
CURTIS1243
|
CURTIS1230
|
|
重量Weight
|
|
|
|
蓄電池重量 Battery weight
|
kg
|
48
|
190
|
252
|
288
|
|
自重（包含蓄電池）Service weight with battery
|
kg
|
285
|
580
|
600
|
840
|
848
|
